 Description
EVOPLUS SMALL electronic circulators can be used
in heating, ventilation and air conditioning systems for
residential and commercial buildings. In all correctly sized
installations, the electronically controlled wet rotor pumps
constantly ensure sufficient power and, simultaneously,
lower noise emissions, greater comfort and a significant
reduction in running costs. All models fitted with flanged
pump body are available in both single and the twin
versions. The user interface is easy to use and easy to
understand.

Features

Circulator protection rate: IP 44.
Insulation class: F.
Standard voltage: single-phase 220/240V, 50/60Hz.
In accordance with European standards:
EN 61800-3 - EN 60335-1 - EN 60335-2-51.
Operating range: from 2 to 12 m3/h with head up to
11 meters.
Liquid Temperature range: from -10 °C to 110 °C.
Pumped liquid: clean, free from solids and mineral oils,
not viscous, chemically neutral, close to the properties of
water (max. glycol contents 30%).
Maximum working pressure: 16 bar (1600 kPa).
Standard flanging: The single version is available with
1 1/2” and 2” threaded ports and with flanged ports DN
32 and DN 40, PN 6 / PN 10 / PN 16.
The twin version is available with flanged pump body DN
32 and DN 40, PN 6 / PN 10 / PN 16.
Installation: with horizontal motor shaft.
